GE Industrial CL03A300T1 contactor that is rated for 25 AMPS AC-3 (32 AMPS AC-1), 15 H.P. @ 460 volt 3-phase and has a 24v50/60Hz AC rated coil (must specify coil voltage above). This 3 pole contactor comes with screw terminals and mounts on standard 35MM DIN rail for quick installation and removal. The GE CL03A300T1 contactor is IEC rated and is the suggested replacement for the CL25A300T1 contactor and optional RT1 overload relays can be mounted to the load side for complete motor protection.
|Coil Voltage||24 volt AC coil|
25 AMP AC-3
32 AMP AC-1
15 H.P. @ 460 volt
7.5 H.P. @ 230 volt
|Number of Power Poles||3|
GE offers a line of 3 pole IEC and UL rated contactors that range from 5 H.P. @ 460volt up to 80 H.P. and accessories such as 4 pole auxiliary contact blocks and overload relays are available. Each contactor has the option to be mounted on the DIN rail or screwed to the base plate a panel for easy installation. 1 base contact (normally open) comes standard and each GE contactor has screw termination for easy wiring.
