Product Description
LS Metasol GMD-12M 3-pole contactor rated for 3 H.P. @ 230 volt, 7.5 H.P. @ 460 volt 3 phase and has a DC rated coil (specify coil voltage above). This 12 AMP AC-3 contactor (20 AMP AC-1) comes with screw terminals, can be mounted on DIN rail or screwed to the panel back plate and comes with one normally open base mounted auxiliary contact. Motor protective thermal overload relays can be added to the bottom of the Metasol GMD-12M contactor for complete motor protection. The manufacturer recommends this contactor as a replacement for the obsolete Benshaw RSC-12M contactor series
| AMP rating |
12 AMP AC-3 20 AMP AC-1 |
| Coil Voltage | DC rated Coil |
| Horsepower |
7.5 H.P. @ 460 volt 3 H.P. @ 230 volt |
| Mounting | DIN rail or base mount |
Description
- 3-pole(NO) main contact
- Finger proof design
- DIN rail or screw mountable
- AC or DC control in different physical size
- Front/side mountable accessories available
- Direct mountable overload relay available Rating
- 1NO Auxiliary contact built-in as standard.
Sealed structure has improved its safety features so that no arc flash is exposed. In order to emphasize its durability as an industrial device, Metasol LS GMC series adopt simple design form and sophisticated shape applying diamond cut concepts on product surface.
