Siemens 3RA2317-8XB30-1BB4 12 AMP Size S00 reversing contactor with a 24 volt DC coil - mechanically interlocked with line and load side wiring harness
Click here to view a PDF file on this Siemens 3RA Reversing Contactor
The Siemens 3RA2317-8XB30-1BB4 reversing contactor basic units can be extended with various auxiliary switch blocks, depending on the application: Size S00 (3RT201) Contactors with one NO contact as the auxiliary contact and with either screw or spring-type connections, identification number 10E, can be extended to obtain contactors with 2, 4 or 5 auxiliary contacts in accordance with EN 50 012 using auxiliary switch blocks. The identification numbers 11E, 22E, 23E and 32E on the auxiliary switch blocks apply to the complete contactors. These auxiliary switch blocks cannot be combined with contactors that have an NC contact in their basic unit, identification number 01, as these are coded.
All size S00 contactors with one auxiliary contact, identification number 10E or 01, and the contactors with 4 main contacts can be extended to obtain contactors with 3 or 5 auxiliary contacts (contactors with 4 main contacts: 2 or 4 auxiliary contacts) according to EN 50 005 using auxiliary switch blocks with identification numbers 40 to 02. The identification numbers on the auxiliary switch blocks apply only to the attached auxiliary contacts
