Product Description
| AMP Rating |
115 AMP AC-3 160 AMP AC-1 |
| Coil Voltage | AC or DC (must specify) |
| Horsepower |
100 H.P. at 460 volt 50 H.P. at 230 volt |
| Terminals | Screw |
| Mounting | Screw or DIN rail |
Product Description
Eaton’s new line of XTCE contactors and starters includes non-reversing and reversing contactors, overload relays and a variety of related accessories. Because XTCE meets IEC, UL®, CSA® and CE standards, it is the perfect product solution for IEC applications all over the world. The compact, space saving and easy to install XTCE line of IEC contactors and starters is the efficient and effective solution for customer applications from 7A to 2450A.
Features and Benefits
- AC control from 12V to 600V 50/60 Hz
- DC control from 12V to 220V
- Available with screw or spring cage terminals
- Reversing or non-reversing contactors and starters
- Non-reversing starters to 650A
- IP20 finger and back-of hand proof
- Large ambient temperature range, 25 to 50°C [–13 to 122°F]
- AC and DC controlled contactors in the same compact frame
- Low power consumption AC and DC coils
- Plug-in accessories for reduced installation time
- Coil replacement on Frames C–N (18–820A)
- Contact replacement on Frames D–N (40 –820A)
- Integrated suppressor 7–150A DC operated contactors and 185–2000A AC and DC operated contactors
