Product Description
WEG RW27-1D3-U008 Thermal Overload Relay
The WEG RW27-1D3-U008 is a compact thermal overload relay designed to provide dependable protection for three-phase motors in industrial and commercial applications. Engineered for direct mounting to compatible WEG contactors, this relay features an adjustable trip range to match the motor’s full-load amperage (FLA), helping prevent overheating, nuisance tripping, and costly motor damage in HVAC systems, pumps, compressors, and automation panels.
Quick Specifications
- Product Type: Thermal Overload Relay
- Protection Class: Class 10
- Trip Setting: Adjustable (set to motor nameplate FLA)
- Application: Three-Phase Motor Protection
- Mounting: Direct mount to compatible WEG contactors
- Auxiliary Contacts: 1 N.O. / 1 N.C. (Built-in)
Application Information
| Use Case | Details |
|---|---|
| Motor Starter Protection | Adjust dial to match motor full-load amps for accurate protection |
| HVAC & Pumps | Protects compressors, fans, and pump motors |
| Industrial Automation | Prevents overload damage in motor control panels |
Product Features
- Adjustable Thermal Protection: Matches motor full-load amperage for reliable performance.
- Phase-Loss Sensitivity: Provides added protection against single-phasing conditions.
- Manual / Automatic Reset: Flexible reset configuration for different applications.
- Direct Mount Integration: Designed for seamless compatibility with WEG contactors.
- Industrial Durability: Built for long-term operation in demanding environments.
Stock Item – Order before 4:00 PM EST for Same-Day Shipping.
