RSC-800-U120

Product Description

Benshaw RSC-800-U120 3 pole, 800 AMP AC-3 (900 AMP AC-1) contactor with a 100-127 volt AC rated coil and two side mounted auxiliary contacts, each with 1 normally open (N.O.) and 1 normally closed (N.C.) contact set. This IEC contactor is rated for 300 H.P. at 230 volt, 600 H.P. at 460 volt, has bolt on terminals and an easy withdrawal coil for fast replacement.

Click here for a catalog page
on this RSC-800 contactor

	Click here for a replacement coil
	Click here for a replacement contact kit

Benshaw RSC contactor highlights

Benshaw contactors are used for controlling single and three phase motors and for switching resistive or inductive loads up to 660 VAC. The RediStart™ contactor line is built and tested to world leading electrical and mechanical standards.

Key Advantages:

• World’s longest electrical and mechanical lifespan
• UL/CSA, IEC, NEMA, BS, EN, VDE ratings
• Direct mount thermal overload relays
• Full line of field installable, modularized accessories
• Device marking strip
• AC or DC coil options Standard features:
• Din rail mountable to 85 amps
• Full product family to 800 amps
• Direct mount overload relays
• Draw out cassette coils above 85 amps
• Integral coil surge suppression above 85 amps
• Low coil power consumption
• Phase barriers supplied standard
• Uni-directional mounting
• Extremely long lifespan
• Compact size
• Unit identification marker RSC-9~85
• Finger proof design
• DIN rail or screw mountable
• Top/side mount accessories
• Small physical size
• Dual auxiliary contacts above 22A
• Integral voltage barriers RSC-100~800
• Draw out cassette type coil
• Wide voltage range coils
• Integral coil surge suppression
• Dual auxiliary contacts

  Only Benshaw has a two year guarantee. Every Benshaw Contactor is guaranteed for two full years. Other manufacturers limit their warranties to just one year. But at Benshaw, we believe that, because we build them better, we can guarantee them longer. We call that “the Benshaw Promise.”
