Product Description
Moeller Electric/Eaton PKE32-XTU-32 starter with electronic trip module AMP range from 8 to 32 AMPS, Selectable Class 5 through 10 and rotary on/off handle . Tool-less installation of electronic trip module and snaps onto DIN rail.
NOTE: If you are switching from the old style PKZ2 to the PKE series, all components and accessories, including the ZM trip module, need to be replaced
Click here for a spec file on this PKE electronic starter
The functional safety and the service life of a motor depends mainly on the motor protection. Motor-protective circuit-breakers PKE32-XTU-32 with electronic wide-range overload protection offer an interesting alternative to the bimetal solutions here and complement the intelligent PKZ2 series from Eaton. They provide the highest level of flexibility featuring a compact and modular design with its plug-in control unit. Control units are also available for system protection applications. The PKE32-XTU-32 can be re-equipped in a single step for motor and system protection with various plug-in control units.
