Product Description
Eaton/Moeller M22-I1-PG single hole surface mounted enclosure with 22MM notched hole for all RMQ-Titan series of push buttons, selector switches, indicator lights and emergency stop buttons. This gray and black enclosure has spaces for three base mounted contact blocks, either M22-KC10 normally open or M22-KC01 normally closed, and also a center slot for a LED if an illuminated pilot device is used. The enclosure for the M22-I1-PG is rated for IP67 for wash down applications and are intended for harsh environments.
Moeller’s RMQ-Titan pilot devices successfully combine rugged performance with aesthetic appeal. This 22mm line offers a broad combination of operator styles, but are designed with common back-of-panel components to keep inventories down. Many unique features combine to make RMQ pilot devices the smart choice for users who require a handsome machine interface and many options at an economical price.
Extensive range for many applications
The breadth of the RMQ-Titan line is impressive. In addition to a wide array of traditional standard operators, Moeller offers special buttons for special applications. Two and four-operator pushbuttons are available that save valuable real estate on small panels. A four-position joystick and potentiometer also offer application flexibility, while direct-wire pilot lights and an audible alarm module eliminate purchase and stocking of contact blocks and mounting latches.
Most Titan actuators can be fitted to our LS limit Switch bodies, which serve as a compact enclosure with two built-in contacts. To round out the line, most operators are also available with a gold color front ring for added aesthetic appeal.
Convenient and secure installation
The entire line mounts in a standard 22mm notched hole, which is the best assurance against device rotation during installation and long term use. The anti-rotation tab and central nut mounting on each operator allow easy installation, even when the front and back of the panel are not accessible simultaneously. Once installed, all back-of- panel components can be modified while leaving the operator in place. Titan contact blocks provide secure connections with screw terminals for standard applications or cage clamps for high vibration environments.
The meaning of “rugged”
Most RMQ-Titan standard pushbuttons and contact blocks have a mechanical lifespan exceeding five million operations. That’s equivalent to performing one ON/OFF cycle every minute for over 9.5 years! Electrical life ratings reach 1.6 million operations (@230V/0.5A). All contact blocks carry Pilot Duty Ratings of A600/P300 (10A @600VAC and 1A @250VDC).
