Product Description
Lovato TM PL Asymmetrical recycle, independent timing Multiscale AC/DC supply modular timer rated at 12-240vAC/DC
Click here to view a PDF file of this Lovato timer
General characteristics
– Programmable asymmetrical recycle, multiscale, multivoltage. Flasher with independent timing for ON and OFF intervals
– Enabling input of ON or OFF interval
– One relay output with 1 SPDT contact
– Delay time for OFF (pause) interval, adjustable on front by rotary switch: 10-100%
– Delay time for ON (work) interval, adjustable on front by rotary switch: 10-100%
– Green LED indicator for power on
– Red LED indicator for relay state; flashing for delay
– Modular 17.5mm (0.7in) wide; suitable for screw fixing or 35mm DIN rail (IEC/EN 60715) mounting
– Degree of protection: IP40 on front (only when mounted in housing or electric board with IP40); IP20 on terminals.
Certifications and compliance
UL listed for USA and Canada, file E93601.
Compliant with standards: IEC/EN 61812-1.
