Product Description
Eaton XTPR010BC1 manual motor protector that is adjustable from 6.3 to 10 AMPS, has Class 10 tripping characteristic (trips in 10 seconds or less), screw terminals and mounts on standard 35MM DIN rail. This motor starter is permissible for use as a thermal magnetic circuit breaker for use in many domestic and international applications and is also classified as a manual motor protector for simple starting and stopping of motors (though a separate short circuit device must be installed upstream). Commonly you will find the XTPR010BC1 in group motor installations or combined with a XTCE contactor to form a Type E Self Protected combination starter.
| AMP Range | 6.3 to 10 AMPS |
| Trip Class | 10 (10 seconds or less) |
| Terminals | Screw |
| Mounting | DIN rail |
| On/Off | Rotary handle |
Product Description
Eaton’s new XT family of manual motor protectors (MMPs) features a pushbutton or rotary ON/OFF manual disconnect, Class 10 adjustable bimetallic overload relay and fixed magnetic short-circuit trip capability in one compact unit. Two frame sizes are available: Frame B (45 mm) for motors with FLA ratings up to 32A and Frame D (55 mm) covers motor FLA ratings up to 65A.
FEATURES:
- Adjustment dial for setting motor FLA
- DIN rail mount
- Terminal types available:
- Screw terminals
- Screw (line) and spring cage (load) terminals
- Spring cage terminals
- Accessories include:
- Front and side auxiliary contacts
- Trip indicating contacts
- Tamperproof cover for OLR dial
- Undervoltage release
- Shunt trip
- Through-the-door operators
- Enclosures
- Three-phase line side connecting links<BR
