Product Description
Siemens 3RT2038-1NF30 80 AMP Size 2 contactor with a 95 to 130 volt DC coil and 1 normally open and 1 normally closed front mounted auxiliary contact. This Sirius 3-pole contactor comes with screw terminals, mounts on standard 35MM din rail and is rated for 25 H.P. @ 230 volt and 50 H.P. @ 460 volt 3 phase. For complete motor protection, 3RU2136 and 3RB3036 overload relays can be directly mounted to the bottom of the 3RT2038-1NF30 and up to 8 additional auxiliary contacts can be added for signalling control.
AMP Rating : 80 AMPS AC-3 / 90 AMPS AC-1
Coil Voltage : 95 to 130 volt DC
Poles : 3
Base mounted Auxiliary contacts : 1 N.O. & 1 N.C.
Terminals : Screw type
Mounting type : DIN Rail or screw mounted
DESIGN
The 3RT2038-1NF30 contactor is suitable for use in any climate. They are safe from touch to DIN VDE 0106 Part 100. The 3RT contactors are available screw, spring-type, or ring lug connections. An auxiliary contact is integrated in the basic unit of size S00 contactors. The basic units of sizes S0 to S3 only contain the main conducting paths. All the basic units can be extended with auxiliary switch blocks. Cabinet units with 2 NO + 2 NC (terminal designations acc. to EN 50 012) are available as of size S0; the auxiliary switch block is removable. The size S3 contactors have removable box terminals for the main conductor connections. Ring cable lugs or bars can thus also be connected.
CONTACT RELIABILITY
If voltages ≤ 110 V and currents ≤ 100 mA are to be switched, the auxiliary contacts of 3RT contactors and 3RH contactor relays should be used to ensure good contact stability. These auxiliary contacts are suitable for electronic circuits with currents ≥ 1 mA at a voltageof 17 V.
One 4-pole or up to four single-pole auxiliary switch blocks (with screw or spring-type connections) can be snapped onto the front of the contactors. When the contactors are energized, the NC contacts open before the NO contacts close. The terminal designations of the single-pole auxiliary switch blocks consist of location digits on the basic unit and function digits on the auxiliary switch blocks. In addition, 2-pole auxiliary switch blocks (screw-type terminals) are provided for cable entries from above or below in the style of a four-connector block (feeder auxiliary switch). If the available installation depth is restricted, 2-pole auxiliary switch blocks (screw or spring-type connections) can be mounted laterally on the left or right.
