Product Description
Moeller DILM12-10 12 AMP 3 pole 3 H.P. @ 230v, 10 H.P. @ 460v contactor with 1 N.O. base mounted auxiliary contact and an AC rated coil.
Click here to view a PDF file of this Moeller DILM contactor.
The DILM contactor series features dual power terminals on units up to 400A. The clamping chambers are cleverly designed to apply sufficient holding pressure to cables of varying sizes. Conventional designs are often limited by the size of the largest cable in the chamber. The line also features ingenious mechanical interlocks (rocker and ball style) that allow fast and easy assembly of contactor combinations without requiring additional space.
Auxiliary contact blocks for new Moeller DILM12-10 contactors have mechanically linked contacts for added safety in control circuits. Mechanically linked auxiliary contacts insure that, throughout the life of the 12 AMP contactor, NO and NC contacts will never close simultaneously…even if a contact welds. In addition, DIL M contactors to 65A have “mirror” contacts, which ensure that all auxiliary contacts (whether built-in or add-on) function correctly in relation to the power contacts.
